BW-CPD-06 for Carport
Brightway Solar
Advantages of PVDF Carport
Patented mute structure design for a serene and comfortable experience.
Rain self-cleaning performance for easy maintenance.
Aesthetic appeal combined with solid durability.
Up to 99% UV blockage to protect vehicles.
Excellent weatherability and heat insulation performance, suitable for various climatic conditions.
Outstanding impact resistance for safety and reliability.
Technical Specifications
| Solar Bracket Parameter | |
| Type | BW-CPD-06 for Carport |
| Material of frame | ≥1.5mm Aluminium profile |
| Standard size of carport | 6000*5950mm |
| Packing size of carport | 2920*560*560mm |
| Gross weight of carport | 480kg |
| The front height of carport | 2.1~2.6m |
| The back height of carport | 1.7~2.1m |
| Bracket | Hot dip galvansied Customizable |
| Membrane | Tensioned Membrane structure with PVDF coating at surface |
| Thickness of the PVDF membrane | 0.85mm |
| Weight of the PVDF membrane | 1050g/m² |
| Thickness of the steel tube | 3.0mm |
| Thickness of foundation | 8mm |
| Warranty | 12 years warranty;25 years service life |
