BWI-HF2000W
Solar Power
Full-Bridge Type
Sine Wave Inverter
Brightway
Carton
Yangzhou
8504403090
Yangzhou, China
10000PCS/Year
L/C, T/T, Western Union, Money Gram
| The machine model | B12P2000-1 | B24P2000-1 | B48P2000-1 | B12P2000-2 | B24P2000-2 | B48P2000-2 |
| The output power | 2000W | |||||
| Peak power | 4000W | |||||
| The input voltage | DC12V | DC24V | DC48V | DC12V | DC24V | DC48V |
| The output voltage | 100VACor110VACor120VAC ±5% | 220VACor230VACor240VAC±5% | ||||
| The no-load current is less than | 1.2A | 0.5A | 0.2A | 1.2A | 0.5A | 0.2A |
| The output frequency | 50HZ±0.5HZ or 60HZ±0.5HZ | |||||
| Output waveform | Pure sine wave | |||||
| Waveform distortion | THD<3% | |||||
| USB | 5V 1A | |||||
| Highest output efficiency | MAX94% | |||||
| Input voltage range | 10-15.5V | 20-31V | 40-61V | 10-15.5V | 20-31V | 40-61V |
| Under-voltage alarm | 10.5±0.5V | 21±0.5V | 42±1V | 10.5±0.5V | 21±0.5V | 42±1V |
| Under voltage protection | 10±0.5V | 20±0.5V | 40±1V | 10±0.5V | 20±0.5V | 40±1V |
| Over voltage protection | 15.5±0.5V | 31±0.5V | 61±1V | 15.5±0.5V | 31±0.5V | 61±1V |
| Owe pressure recovery | 13±0.5V | 24±0.5V | 48±1V | 13±0.5V | 24±0.5V | 48±0.5V |
| Overpressure recovery | 14.8V±0.5V | 29.5V±0.5V | 59V±1V | 14.8V±0.5V | 29.5V±0.5V | 59V±0.5V |
| Protection function | Undervoltage/overvoltage | LED red light on, automatic recovery alarm | ||||
| overload | LED red light on, lock alarm | |||||
| A temperature | LED red light on, automatic recovery alarm | |||||
| A short circuit | LED red light on, automatic recovery alarm | |||||
| Input the reverse | Diodes or MOS | |||||
| Working environment temperature. | -10°- +50° | |||||
| Storage environment temperature | -30°- +70° | |||||
| Product size | 305*169*86 | |||||
| The net weight | 4.2 | |||||
| Quantity/carton | 4 | |||||
| Packing size | 425*211*130 | |||||
| The quality assurance | 1years | |||||
| Start the | Bipolar soft start | |||||
| cooling | Air cooling | |||||
| The machine model | B12P2000-1 | B24P2000-1 | B48P2000-1 | B12P2000-2 | B24P2000-2 | B48P2000-2 |
| The output power | 2000W | |||||
| Peak power | 4000W | |||||
| The input voltage | DC12V | DC24V | DC48V | DC12V | DC24V | DC48V |
| The output voltage | 100VACor110VACor120VAC ±5% | 220VACor230VACor240VAC±5% | ||||
| The no-load current is less than | 1.2A | 0.5A | 0.2A | 1.2A | 0.5A | 0.2A |
| The output frequency | 50HZ±0.5HZ or 60HZ±0.5HZ | |||||
| Output waveform | Pure sine wave | |||||
| Waveform distortion | THD<3% | |||||
| USB | 5V 1A | |||||
| Highest output efficiency | MAX94% | |||||
| Input voltage range | 10-15.5V | 20-31V | 40-61V | 10-15.5V | 20-31V | 40-61V |
| Under-voltage alarm | 10.5±0.5V | 21±0.5V | 42±1V | 10.5±0.5V | 21±0.5V | 42±1V |
| Under voltage protection | 10±0.5V | 20±0.5V | 40±1V | 10±0.5V | 20±0.5V | 40±1V |
| Over voltage protection | 15.5±0.5V | 31±0.5V | 61±1V | 15.5±0.5V | 31±0.5V | 61±1V |
| Owe pressure recovery | 13±0.5V | 24±0.5V | 48±1V | 13±0.5V | 24±0.5V | 48±0.5V |
| Overpressure recovery | 14.8V±0.5V | 29.5V±0.5V | 59V±1V | 14.8V±0.5V | 29.5V±0.5V | 59V±0.5V |
| Protection function | Undervoltage/overvoltage | LED red light on, automatic recovery alarm | ||||
| overload | LED red light on, lock alarm | |||||
| A temperature | LED red light on, automatic recovery alarm | |||||
| A short circuit | LED red light on, automatic recovery alarm | |||||
| Input the reverse | Diodes or MOS | |||||
| Working environment temperature. | -10°- +50° | |||||
| Storage environment temperature | -30°- +70° | |||||
| Product size | 305*169*86 | |||||
| The net weight | 4.2 | |||||
| Quantity/carton | 4 | |||||
| Packing size | 425*211*130 | |||||
| The quality assurance | 1years | |||||
| Start the | Bipolar soft start | |||||
| cooling | Air cooling | |||||
