| Quantity: | |
|---|---|
BWBL-5120
Brightway
8507200000
Production Description :
Long cycle life
Using high-quality powerful lithium iron phosphate batteries, the cycle life is more than 6000 times
at 80%DOD, lifelong for 10-15 years
High quality prismatic lithium iron phosphate battery
Higher capacity, good storage, higher current, longer life
Low internal resistance and high current
Low internal resistance of the battery, excellent continuous high current discharge performance
Intelligent BMS battery protection
Built-in intelligent BMS (battery management system), effectively avoiding overcharge,
overdischarge, overcurrent, short-circuit, balance and other problems
Communicated with multiple brands inverter same time
Battery BMS supports simultaneous
communication and docking with multiple brands inverter
Good safety performance
Extreme safety test, no fire, no explosion, no leakage
Technical parameters
| Specifications | BW-SE3600 | |
| Nominal Voltage | 48 V | |
| Nominal Capacity (40°C , 0.5C) | 750 Ah | |
| Weight (Approximate) | 305Kg | |
| Energy | Normal energy (40°C , 0.5C) | 36kWh |
| Volumetric energy density | 95Wh/L | |
| Gravimetric energy density | 96Wh/kg | |
| Shelf Dimensions (L*W*H) | Length* Width* Height | 53.2*40*127cm |
| Standard Discharge 25°C | Max. constant current | 150A |
| Cut-off voltage | 37.5V | |
| Standard charge 25ºC | Charge Voltage | 54.7V |
| Max. constant current | 100A | |
| Calendar life | 25ºC | >5 years |
| Cycle life (0.5C, 25ºC) | 60% DOD 4000 cycles | |
| Operating temperature | Charging: 1ºC~50ºC | |
| Discharging: -7ºC~57ºC | ||
| Battery module 48V 150Ah | ||
| Voltage | Nominal | 48V |
| Charge current | Max | 100A |
| Discharge current | Max | 150A |
| Operating voltage | 37.5V-54.7V | |
Professional package:
What we Do: ALL-IN-ONE SOLUTIONS
