Product features:
1. Advanced intelligent control technology of dual-cpu single chip microcomputer, featuring high reliability and low fault rate;
2. Pure sinusoidal output with strong loading capacity and wide application range;
3. It has complete protection functions (overloading protection, internal over-temperature protection, output short-circuit protection, input under-voltage protection, input over-voltage protection, etc.), which greatly improves the reliability of the product;
4. Small size and light weight. CPU centralized control and patch technology are adopted internally to make the volume very small and light;
5. Intelligent control of the cooling fan, which adopts CPU to control the working state of the cooling fan, greatly extends the service life of the fan, saves power and improves working efficiency;
6. Low noise and high efficiency
Scope of application
1. Vehicle-borne equipment series: ** vehicles, police cars, medical ambulances, ships, traffic lights, etc.;
2. Industrial equipment series: solar energy, wind power generation, gas discharge lamp, etc.
3. Office: computer, printer, copier, scanner, digital camera, etc.
4. Kitchen appliance series: microwave oven, battery oven, refrigerator, etc.
5. Household electrical equipment: electric fans, vacuum cleaners, air conditioners, lighting lamps, etc.;
6. Power tools series: electric saw, drilling machine, punching machine, air compressor, etc.;
Technical indicators
The machine model | B12P4000-1 | B24P4000-1 | B48P4000-1 | B12P4000-2 | B24P4000-2 | B48P4000-2 |
The output power | 4000W | |||||
Peak power | 8000W | |||||
The input voltage | DC12V | DC24V | DC48V | DC12V | DC24V | DC48V |
The output voltage | 100VAC or 110VAC or 120VAC ±5% | 220VAC or 230VAC or 240VAC ±5% | ||||
The no-load current is less than | 2A | 1A | 0.5A | 2A | 1A | 0.5A |
The output frequency | 50HZ±0.5HZ or 60HZ±0.5HZ | |||||
Output waveform | Pure sine wave | |||||
Waveform distortion | THD<3% | |||||
USB | 5V 1A | |||||
Highest output efficiency | MAX94% | |||||
Input voltage range | 10-15.5V | 20-31V | 40-61V | 10-15.5V | 20-31V | 40-61V |
Under-voltage alarm | 10.5±0.5V | 21±0.5V | 42±1V | 10.5±0.5V | 21±0.5V | 42±1V |
Under voltage protection | 10±0.5V | 20±0.5V | 40±1V | 10±0.5V | 20±0.5V | 40±1V |
Over voltage protection | 15.5±0.5V | 31±0.5V | 61±1V | 15.5±0.5V | 31±0.5V | 61±1V |
Owe pressure recovery | 13±0.5V | 24±0.5V | 48±1V | 13±0.5V | 24±0.5V | 48±0.5V |
Overpressure recovery | 14.8V±0.5V | 29.5V±0.5V | 59V±1V | 14.8V±0.5V | 29.5V±0.5V | 59V±0.5V |
Protection function | Undervoltage/overvoltage | LED red light on, automatic recovery alarm | ||||
overload | LED red light on, lock alarm | |||||
A temperature | LED red light on, automatic recovery alarm | |||||
A short circuit | LED red light on, automatic recovery alarm | |||||
Input the reverse | Diodes or MOS | |||||
Working environment temperature. | -10°- +50° | |||||
Storage environment temperature | -30°- +70° | |||||
Product size | 430*200*145(mm) | |||||
The net weight | 8.7(kg) | |||||
Quantity/carton | ||||||
Packing size | 460*240*190(mm) | |||||
The quality assurance | 1years | |||||
Start the | Bipolar soft start | |||||
cooling | Air cooling |
